## GRAPH Course

# Cycle basis

Let $E$ the set of edges, **ordered**. If you are not given an order for the edges, create one. If the graph is not directed, arbitrarily pick a direction for each edge.

We are writing each cycle as a vector of values such as $C_n = (0, ...,1,-1)$

- $0$: if the edge is not inside the cycle
- $1$: if the edge is inside the cycle, in the same direction
- $-1$: if the edge is inside the cycle, not in the same direction

A cycle basis $B$ is a set of cycles as vectors, so that the basis is linearly independent and generating (`libre et génératrice`

). Something like $B=\{C_1,C_2\}$.

We are written $\mu(G)$ (mu) the number of elements of a cycle basis, with $\mu(G) = m − n + p$ and $p$ the number of connected components.

## Co-cycle basis

We are calling co-cycles (`cocycles`

) of $A$, the set of arcs incident of $A$, noted $\omega{(A)}$.

- $1$: if an edge $(a,b)$ got $a$ inside the co-cycle, $b$ outside
- $-1$: if an edge $(a,b)$ got $b$ inside the co-cycle, $a$ outside
- $0$: otherwise

A co-cycle basis $B$ is a set of co-cycles as vectors so that the basis is linearly independent and generating (`libre et génératrice`

). Something like $B=\{C_1,C_2\}$.

We are written $\gamma(G)$ (gamma) the number of elements of a cycle basis, with $\gamma(G) = n - p$ and $p$ the number of connected components.

## Exercise 1 - cycle basis

The edges' set for the following graph is

@ E = \{(a,b),(a,c),(a,d),(b,c),(b,f),(c,e),(c,f),(d,e),(e,f)\} @

- Give the vectors for the cycles
- $(bcfb)$
- $(abfeda)$

- $(bcfb)$ is a linear combination of 2 cycles. Which ones?
- What's $\mu(G)$?
- Give a cycle basis $B$, which mustn't include both $(bcfb)$ and $(abfeda)$.

we are simply doing what is explained above

$(bcfb) \to (0,0,0,1,-1,0,1,0,0)$

- the 4th value is $1$ since $bc$ is in $bcfb$ in the same order
- the 5th value is $-1$ since $bf$ is in $bcfb$ ($fb$) but not in the same order
$(abfeda) \to (1,0,-1,0,1,0,0,-1,-1)$

one answer would be $(bcfb) = (bcefb) + (ecfe)$ @ (bcfb) \to (0,0,0,1,-1,0,1,0,0) = (0,0,0,1,-1,1,0,0,1) + (0,0,0,0,0,-1,1,0,-1) = (bcefb) + (ecfe)$ @

$\mu(G) = m - n + p \Leftrightarrow 9-6+1 = 4$

$B = \{(abca), (cfec), (acefba), (adeca)\}$

You must look for cycles that have an arc that is not in a cycle you already created so that you are sure that can't get it by linear combination. Notice that we got $4$ cycles inside $B$, as expected.

## Exercise 2 - co-cycle basis

The edges' set for the following graph is

@ E = \{(a,b),(a,c),(a,d),(b,c),(b,f),(c,e),(c,f),(d,e),(e,f)\} @

- Give the vectors for the co-cycles
- $(abf)$
- $(ae)$

- $(ae)$ is a linear combination of 2 co-cycles. Which ones?
- What's $\gamma(G)$?
- Give a cycle basis $B$, which mustn't contain co-cycles of one vertex.

we are simply doing what is explained above

$(abf) \to (0,1,1,1,0,0,-1,0,-1)$

- the $2^{nd}$ value $(a,c)$, $a$ is inside, $c$ outside so $1$
- the $7^{th}$ value $(c,f)$, $c$ is outside, $f$ inside so $-1$
$(ae) \to (1, 1, 1, 0, 0, -1, 0, -1, 1)$

one answer would be $(ae) = (a) + (e)$ (because they are a stable set)

$\gamma(G) = n - p \Leftrightarrow 6-1 = 5$

$B' = \{(abc), (bcf), (cfe), (aced), (abfed)\}$

Notice that we got $5$ co-cycles inside $B$, as expected.
